CNC Wire Bending Machine Manufacturers in India

Whatsapp Now

Contact With Us

Nisha Engineering Works is one of the acclaimed CNC Wire Bending Machine Manufacturers in India, Suppliers and Exporters in India. We specialize in producing advanced CNC-controlled wire bending systems designed for high-speed, accurate, and complex wire forming tasks across industrial applications. Our Automatic CNC Wire Bending Machine deliver exceptional precision using automated servo-driven motions that bend wire into multiple shapes with perfect repeatability. Our machines are commonly used in the automotive industry, display rack, home appliance, and industrial fabrics to enhance the quality of output, decrease the reliance on labour and streamline the processes of mass-production. Nisha Engineering Works offers high accuracy, consistency, and durability in result.

What does a CNC Wire Bending Machine do?

It is an automated device that bends wires into complex shapes of a pattern under a series of axes that are servo controlled, programmed via a CNC software that can set the angle at which wires bend, and provide the sequence of 3D bends. It guarantees the absolute dimensional precision and does not require the use of hands even in the high volume production setup.

Types of CNC Wire Bending Machines

Being established CNC Wire Bending Machine Manufacturers in India, we provide multiple machine types to match different wire materials, thicknesses, and production speeds.

2D CNC Wire Benders: These machines bend only a wire on a plain, but they typically operate on the X and Y axes. Perfect in producing flat and simple designs like hooks, hangers, frames and wire grids.
3D CNC Wire Benders: These systems bend wire in multiple directions, including X, Y, Z, and rotational axes. They can produce complex three-dimensional wire forms.

Technical Specification of CNC Wire Bending Machine

Being reliable CNC Wire Bending Machine Suppliers in India, we design machines capable of handling varied production needs and material types.

Category	Specification	Details
Product Details	Wire Diameter	6 mm
	Layout	Horizontal
	Bending Material	Wire
	Max Bending Radius	500 mm
	Max Bending Angle	180°
	Voltage	380 V
	Power Source	Electric
	Material	Mild Steel
	Automation Grade	Automatic
Price Info	Approx. Price	Rs 6,00,000 / Unit
Performance & Capacity Parameters	Wire Diameter Range	Typically 0.5–14 mm for 3D machines; 2–6 mm for 2D machines (Your model: 6 mm)
	Material Compatibility	MS, SS, galvanized wire, spring steel; max diameter varies by material
	Number of Axes	2 to 12 axes depending on model complexity
	Bending Angle Range	0.1° to 240° (Your model supports 180°)
	Bending Radius	Minimum 0.5 mm; up to 500 mm for larger forms (Your model: 500 mm)
	Max Wire Length Handling	Unlimited with coil feeding
Speed & Accuracy Parameters	Bending Speed	400°–800° per second
	Wire Feeding Speed	40–100 m/min or 1400–1700 mm/sec
	Bending Accuracy / Repeatability	±0.1 mm or ±0.1°
Mechanical & Electrical Parameters	Machine Dimensions (L × W × H)	Varies by model (e.g., 3690 × 1465 × 1977 mm)
	Machine Weight	400 kg to 4000+ kg depending on build
	Power Source & Consumption	380V, 3-phase; servo motor power varies by capacity
	Air Pressure Requirement	5–6 KG/CM²
Other	Coiler Capacity	Up to 1500 kg depending on payoff station

Features of our CNC Wire Bending Machines

As CNC Wire Bending Machine Exporters in India, we offer advanced features to meet modern industrial forming expectations.

High-Precision Servo Control System: Servo-driven feed, rotation, and bending ensure exact wire positioning and consistent angles. This precision maintains uniformity across large production batches.
Advanced CNC Programming Capability: The machine stores multiple bending programs with 2D or 3D shapes. Operators can design complex parts using intuitive software for repeatable production.
Efficient Wire Straightening & Feeding: Integrated straightening rollers and servo feeders ensure smooth wire entry with minimal vibration. This improves forming accuracy and reduces material waste.
Heavy-Duty Bending Structure: The frame and bending components are designed to withstand continuous production loads. This ensures stable operation even during high-speed bending cycles.
Automated Cutting & Finishing: After bending, wires are automatically cut to exact length for consistent part quality. This eliminates manual cutting and increases production efficiency.

Applications of CNC Wire Bending Machines

As CNC Wire Bending Machine Suppliers in India, we supply machines used across numerous industries requiring accurate wire forms.

Automotive & Transportation Manufacturing: In the manufacturing of seat frames, spring shapes, clips, brackets and wire automotive items. Its accuracy is in favour of mass production.
Furniture & Display Rack Fabrication: Ideal for shaping wire forms used in shelves, baskets, stands, and modular display fixtures. The machine enhances aesthetic and structural design output.
Household Appliance Components: Used to make wire handles, frames, supports, and internal appliance structures. Its precision ensures consistent, durable components.
Industrial Hardware & General Fabrication: Supports the production of hooks, rings, clamps, and custom wire pieces for industrial use. It allows fast, repeatable shaping for varied requirements.
Electrical, HVAC & Mesh Manufacturing: Used to form wire parts for grills, electrical accessories, HVAC grids, and welded mesh products. Its speed supports high-volume fabrication.

Why Choose Us?

Advanced CNC automation and servo controls: Our machines provide unmatched precision and speed, helping industries achieve high-quality wire forms with minimal manual involvement.
Customised for material, diameter & production needs: We tailor bending capacity, tooling, automation level, and software features to ensure our machines fit perfectly into any industrial workflow.
Complete service, training & technical support: Our dedicated support team ensures smooth installation, operator training, and long-term machine maintenance for uninterrupted performance.

Nisha Engineering Works is one of the trusted CNC Wire Bending Machine Manufacturers in India, Suppliers and Exporters in India. Our machines are admired because of their automation capacity, precision, and longevity in the large scale production settings. All the models are designed to achieve high performance, less labour input and maintenance of a uniform wire forming output. We are also determined to come up with new bending solutions that improve the efficiency of manufacturing and facilitation of the workflow processes. Connect with us today to learn more or request a customised quotation for your CNC Wire Bending Machine in India.

FAQ’s

It supports mild steel, stainless steel, galvanised wire, copper-coated wire, and spring steel depending on model capacity.

Yes, 3D CNC wire benders allow multi-axis programming for complex and multi-radius wire forms.

Absolutely. Its automation, speed, and repeatability make it ideal for large-scale manufacturing across multiple industries.
